MAGELLAN VI PASSIVE BASS MODULE

The MAGELLAN VI su is quite possibly the best of the group in general terms. Its driver uses an extremely stiff low mass single piece convex aluminum cone. The tuning for this model results in unprecedented performance with speed and warmth combined in a package guaranteed to pass the WAF many times over. The Magellan VI su will integrate well at crossover points as high as 200Hz with no signature. Low vibration is inherent to the design and allows flexible placement even amongst your existing components in the rack. You can use the MAGELLAN VI su singly or in pairs powered by our TBI 200 su or you can use your favorite high quality subwoofer amplifier or amplifier/crossover combination to customize your application.

MAGELLAN VI su (passive) Product Brochure
MAGELLAN VI su (passive) Curves Charts

Magellan VI su passive subwoofer

Subwoofer / Amp options
Foreign Shipping Instructions

Check for Demo Units


(Front)

(Back)

(Bottom)

Specifications:

FREQUENCY RESPONSE 20 Hz 200 Hz (-6DB)
POWER CAPACITY 100 W RMS (175W IHF)
SENSITIVITY 90db 1w/1m @ 35Hz
DRIVER 6.5 Convex Single Piece Aluminum Cone
CONNECTION 5-way binding posts
IMPEDANCE 8 ohms nominal
ACCESSORIES Brass Vibration Isolators-Standard Large Rubber Feet
DIMENSIONS
WIDTH 14.5 inches ( 368.3 mm ))
DEPTH 14.5 inches ( 368.3 mm )
HEIGHT 5.5 inches ( 139.7 mm ) no feet ( 7 inches w/spikes )
WEIGHT 15 lbs ( 6.8 kg )
Retail - $800.00

Compatibility Chart - 1 to 10

Monitors Electrostatic & Dynamic Panels High sensitivity systems
Small towers -10 Stand Mounts minis - 8 Horns high x-over - 7
Small towers -10 low x-over panels < 100Hz - 8 Horns low x-over - 9
Large Towers -9 Dynamic Planar < 80 Hz - 8 Direct Radiator - 9
